Specifications:
| Box (WxLxH) | 101"x12'x66" |
| Interior (WxLxH) | 98"x11'10"x64" |
| Overall (WxLxH) | 102"x7'8"x16'2" |
| Deck Height | 25" |
| Hitch Height | 23" |
| Rear Door Opening | 93" x 62" |
| Coupler Rating / Ball Size | 3500# / 2" Ball |
| Axle(s) - Qty/Rating | 1-3500# Idler |
| Wheels | 12" E-Rated |
| Tires | ST145/R12E |
| GVWR | 2990# |
| Curb Weight | 1058# |
| Payload | 1932# |
| Power Connection | 4-Way Flat |
Features:
- All-Aluminum Construction
- 16" O/C Wall & Roof Studs
- 24" O/C Floor Crossmembers
- 2"x5" Subframe Tubing
- Torsion Ride Suspension
- Screwless .030" Bonded Side Panels
- One-Piece Aluminum Roof
- Rear Ramp Door w/ Spring Assist
- 19"x58" Front Access Door
- 5/8" Water Resistant Decking
- Full Length Slide Track w/ Ski Tie Down Bars (12' & 14' Models)
- Full Length Slide Track w/ Sliding D-Rings (16'+ Models)
- 12" Plywood Kickplate
- Interior Dome Light
- Louver Vents
- Recessed LED Lights
- Wishbone Tongue w/ Straight Coupler
- Round Radius Diamond Plate Nose
- 1200# Wheel Jack
- (2) 5000# Safety Chains
- Limited 4-Year Warranty
